Problem Solving
14
Staple Jams in the Staple Cartridge (For Finisher-A1)
The following describes how to clear staple jams in the Finisher-A1 (optional).
1
Make sure that the machine has
stopped, and open the front cover
of the finisher.
2
Take the staple cartridge out of the
machine.
Note • The staple cartridge is firmly
inserted. A slight force is
required to pull the cartridge
out of the finisher.
3
After removing the staple cartridge,
check inside of the finisher for any
remaining staples.
4
Pull up the metal part of the staple
cartridge as shown in the figure.
5
Remove the jammed staples (1),
and return the metal part pulled up
in step 4 to the original position (2).
CAUTION
Be careful in removing jammed
staples.
1
2
To Next Page
