After pressing the mode button, press the menu button and set Auto Layout to ON.
Once you set it to ON, the settings for scaling, area determination mode, paper margins
and scaling mode all become active.
îš„Scaling
Determines the setting to either enlarge or reduce (scaling) the document size so that
the document size fits the paper size.
îš„Area Determination Mode
Based on HP-GL data, the methods for obtaining the active coordinates area are as
follows:
Auto
The method for determining the active coordinate area is automatically selected from
among PS, IW, IP and Adapted.
In this mode the order of priority is PS, IW, IP, Adapted.
IW
The area specified by the very last IW command in the data becomes the active
coordinate area.
If there are no IW commands in the data, the active coordinate area is determined by
Adapted.
IP
The area that encompasses all the areas specified by IP commands in the data
becomes the active coordinate area.
If there are no IP commands in the data, the active coordinate area is determined by
Adapted.
Adapted
The ACA is determined by the following conditions.
Min/Max position coordinates plotted by drawing commands
Max font size specified within the page
Max line width
PS
The area that encompasses all the areas specified by PS commands in the data
becomes the active coordinate area.
If there are no PS commands in the data, the active coordinate area is determined by
Adapted.
îš„Paper Margin
Set the range from 0 to 99 mm. The default value is 0 mm. To get the active coordinate
area, subtract the area set in paper margins from the ACA obtained in the area
determination mode.
