HP-GL2 Emulation
469
Appendix
15
îš„Document: Auto, Coordinate Origin: 0 Degrees, Scaling Mode: Paper Size,
Scaling: OFF
îš„Document: Auto, Coordinate Origin: 0 Degrees, Scaling Mode: Active Coordinate
Area, Scaling: ON
îš„Document: Auto, Coordinate Origin: 0 Degrees, Scaling Mode: Active Coordinate
Area, Scaling: OFF
9. HP-GL/2 Emulation Mode Restriction
Using HP DJ750C, which is the emulation target for the HP-GL/2 emulation mode, sets
lines to a round joint if the lines are 0.35mm width or under. A miter joint is not set.
However, using the HP-GL/2 emulation mode of the machine always sets lines to a
miter joint as a default regardless of the line width.
To cancel the default, use a command.
Print Area
Document Size
Paper Size
Print Area
ctive Coordinate Area determined by entered data Paper Size
Print Area
ctive Coordinate Area determined by entered data Paper Size
