3 Maintenance
46
Maintenance
3
2
Hold the staple cartridge by Lever
R1 and pull the staple cartridge
holder to the right.
3
Hold the staple cartridge holder by
the orange lever and remove it
from the finisher.
Note • The staple cartridge is firmly
inserted. A slight force is
required to pull the cartridge
out of the finisher.
4
Pinch both sides of the empty
staple case with your fingers (1),
and remove the staple case from
the cartridge (2).
5
Insert the front side of the new
staple case into the staple cartridge
(1), and then push the rear side
into the cartridge (2).
6
Hold the staple cartridge by the
orange lever, and insert it into the
finisher until it clicks.
7
Close the front cover of the finisher.
Note • If the front cover of the finisher is not completely closed, a message will appear and the
machine will not operate.
1
1
2
1
2
To Next Page
