FujiFilm 3000 - Printer; Scanner

Individual part names

11
ENGLISH
2.3 SCANNER
2.4 PRINTER


Scanner cover
Document eject roller
Platen roller
Cogged belt
Document bay
Platen glass
Document
feed roller
Cutter unit
Cogged belt
Thermal heads
Paper bracket
(right)
Paper feed roller
Paper sensor
Platen rubber
Cutter basePaper bracket (left)
(adjustable according
to paper roll width)
