FujiFilm FinePix A607 - Camera Parts and Features; Major Components; Control Buttons and Dials; Ports and Slots

8
Camera parts and features
VIDEO OUT (Video output)
socket
(P.61)
Self-timer lamp (P.30)
Shutter button
DC IN 3V (Power input) socket
(P.61)
Viewfinder window
Power switch /
lens cover
(P.12)
Flash (P.27)
Cradle connection socket
(USB)socket (P.66)
Lens
xD-Picture Card slot
Battery compartment
Tripod mount
Viewfinder
Battery cover
Viewfinder lamp
LCD monitor
DISP (Display) / BACK button
Strap mount
MENU / OK button
a / (Tele), b/ (Wide)
(P.21)
c/ (Flash) button (P.27)
d / (Macro) button (P.26)
Zoom switch (P.21)
ON (Playback) button
✽ Refer to the pages in parentheses for information on
using the camera parts or features.
