3. Machine Set Up QD002-07
26 NXT Setup Manual
3. At the new position, tentatively set the level blocks in the proper positions for the new
machine.
70 575 650 650 575 70
1384 43.5472.5
1900
1384 43.5472.5
1900
2590
Unit: mm
Front side of the machine
Front side of the machine
1290
70 70
575
575
<8M Base>
<4M Base>
NXTSET002E
