FujiFilm NXT - Page 70

3. Machine Set Up QD002-07
62 NXT Setup Manual
Stand-alone Control - 2M Base - 2M Base - 2M Base
Harness Connection Diagram
A
B
C
D
E
F
G
E
F
Panel flow
RH2012*
CN28A
BRCN1
RH0558*
Disconnect RH0584*, then
connect RH0559*.
BRCN2
BRCN2
BLCN2
RH0559*
BRCN3
(Fixed)
BLCN3
RH0560*
BRCN3
(Cable)
Connected when the
base is used in the
last stage.
BLCN4
BRCN3
BRCN3
Panel loading
signal bracket
(Previous stage)
CN-M1
Panel loading
signal bracket
(Next stage)
RH0070*
Connected when
shipped
CN-M2
CN-M2
CN-M2
CN-M2
Lane 2-F Lane 2-R
RH1186*
Lane 1-F Lane 1-R
RH1186*
Circuit breaker bracket
CN-1
RH0562*
CN-2
To I/F CN28
NXTSET193Ea
G
A
CN27B
CN27A
To I/F CN27
B
HUB
CH6
C
D
BLCN2
BLCN2
CN-M1
RH0067*
Connected when
shipped
2M base
