QD002-07 3. Machine Set Up
NXT Setup Manual 73
2M base
Panel flow
NXTSET198Ea
CN27B
CN27A
CN28A
Right side
module cover
To I/F CN27
HUB
CH6
BRCN1
RH0558*
BLCN2
BRCN2
BRCN2
BLCN2
Connected when
shipped
RH0559*
BLCN3
BRCN3
(Fixed)
BLCN3
BRCN3
Connected when
shipped
RH0560*
BLCN4
RH1163*
Connected when
shipped
RH0067*
CN-M1
CN-M1
CN-M2
CN-M2
Connected when
shipped
RH0070*
RH0583*
RH0528*
RH0584*
RH0583*
Lane 2-F Lane 2-R
RH1186*
Lane 1-F Lane 1-R
RH1186*
Circuit breaker barcket
CN-1
RH0562*
CN-2
Previous stage side Next stage side
RH2012*
A
B
C
D
E
F
G
H
I
4M Base - 2M Base Harness Connection Diagram (2/2)
Panel loading
signal bracket
(Previous stage)
Panel loading
signal bracket
(Next stage)
