3. Machine Set Up QD002-07
74 NXT Setup Manual
Pneumatic Connections
<For the Independent 4M Base (serial No. up to 294)>
Independent 4M base Dependent 2M base
Front view
NXTSET024Ea
Remove the two plugs and attach the T2 tube elbow connector.
T2 tubes (2)
Remove the plugs from these
two locations, and then connect
the T2 tubes.
To Next Page
