FujiFilm NXT - Page 88

3. Machine Set Up QD002-07
80 NXT Setup Manual
2M base
CN27B
CN28ACN27A
To I/F CN27
HUB
CH6
BRCN1
RH0558*
Disconnect RH0584*, then
connect RH0559*.
BLCN2
BRCN2
BRCN2
BLCN2
RH0559*
RH0559*
RH0558*
BLCN3
BRCN3
(Fixed)
BRCN3
BLCN3
RH0560*
RH0560*
BRCN3
(Cable)
BLCN4
BRCN3
BRCN3
RH1163*
RH1163*
Joint harness
Connected when the base
is used in the last stage.
Disconnect RH0070*, then
connect RH0583*.
RH0583*
RH0583*
RH1186*
RH1186*
RH1186*
RH1186*
Circuit breaker bracket
CN-1
RH0562*
RH0562*
CN-2
Previ
ous stage side
Next stage side
CN-M1
CN-M1
CN-M2
CN-M2
Lane 2-F Lane 2-R
Lane 1-RLane 1-F
RH2012*
RH2012*
4M Base - 2M Base - 2M Base Harness Connection Diagram (2/4)
NXTSET200Ea
A
A
B
C
D
E
F
G
H
I
B
C
D
E
F
G
H
I
Panel flow
Connected when
shipped
RH0067*
To I/F CN28
Panel loading
signal bracket
(Previous stage)
Panel loading
signal bracket
(Next stage)
