Ports
This chapter presents the individual hardware components of your device. This will provide
you with an overview of the ports and operating elements on the device. Please familiarise
yourself w ith these components before starting to work with your device.
Front
2
3
4
5
6
7
8
1
1 = Module bay for 5
1
/
4
inch drives
2 = Insert/eject button (CD/D VD) (optional)
3 = Module bay for 3
1
/
2
inch drives
4 = ON/OFF switch
5 = Headphone port
6 = Microphone jack
7 = USB ports
8 = Latch with optional casing lock
