Fujitsu CELSIUS W410 - Installing the Module Holder with Smartcard Reader And;Or WLAN Module

System expansions
Installing the module holder with SmartCard reader
and/or WLAN module
2
2
1
► Push the module holder into the casing in the direction of the arrow (1).
► Fasten the m odule holder with the screws ( 2).
► C onnect the cables to the boards and the mainboard. Make sure the polarity is correct.
► C lose the casing (see "
Closing the casing", Page 36).
42 Fujitsu Technology Solutions
