System expan sio ns
Removing an acces sible drive
► Open the casing (see "Opening the casing" , Page 35).
1
2
► Disconnect the cables connected to the drive.
► Slide th e clip in the direction of th e arrow (1).
► Pull t he d rive out of the casing in the direction of the arro w ( 2).
1
► Remove the drive cover from the drive (1).
1
► Place the drive cover on the holder in the direction of the arrow (1).
► If nece
ssary, make the required s ettings on the remaining hard disk drives.
► If yo u are n o t installing a new drive, reinstall the previously removed cover (optional) for the
purposes of cooling, fire protection and to preven t foreign objects from getting into the casing.
► Clos
e the casing (see "
Closing the casing", Page 36).
Fujitsu Technology Solutions 39
