System expansio ns
Installing a hard disk
► Secure the guide ra ils on the hard disk. Make sure that th e guide openings point downwards.
1
2
► Insert the hard disk into the device (1). Make sure that the label on the ha rd disk faces upwards.
► Slide the hard disk in the direction of the arrow (2) until the clip engages.
Fujitsu Technology Solutions 49
