Technical data
Technical data
Electrical data
Safety standards complied with: IEC 60950-1, EN 60950 -1, UL 60950-1
CSA 22.2 No.60950-1
Protection class: II
Rated vo ltage range 100–240 V
Rated frequency 50–60 Hz (AC)
Max. rated cu rrent 1.2–0.6 A
Dimensions
Width/depth/height:
185 mm x 187.5 mm x 58 mm
Weight
in basic configuration:
approx. 1.8 kg
Ambient condition s
Environment class 3K2
Environment class 2K2
DIN E N 60721-3-3
DIN E N 60721-3-2
Temperature
Operation (3K2) 15 ° C .... 35 °C
Transportation (2K2) –25 °C .... 60 °C
The formation of condensation is not permitted while the device is in operation !
Clearance required to ensure adequate ventilation:
without air vents
with air vents
min. 10 mm
min. 200 mm (exception: underside du ring
vertical operating position, see "
Setting up the
device", Page 16)
The data shee ts of these devices contain further technical data. The data
sheets can be found on our website "
http://ts.fujitsu .com".
54 Fujitsu Technology Solutions
