3 Specify the width of each margin to fill in: top/bottom/left/
right.
The specified area is filled in white or black, according to the
background color.
ATTENTION
Note that if the target range of Page Edge Filler is too wide, some
characters near the edge may appear missing.
ADF
T: top = 0 to 15 mm
B: bottom = -7 to 7 mm
R: right = 0 to 15 mm
L: left = 0 to 15 mm
FB (fi-7240)
T: top = 0 to 15 mm
B: bottom = 0 to 15 mm
R: right = 0 to 15 mm
L: left = 0 to 15 mm
(in 1 mm increments)
Area
HINT
The color of the background is normally white. You can change
the background to black in the scanner driver.
For details, refer to the scanner driver's Help.
Depending on the value specified for the bottom margin in
[Page Edge Filler (ADF)], the Page Edge Filler function
operates as follows:
- 1 to 7 mm
Fills the margin in white, from the detected page bottom.
- -1 to -7 mm
Outputs the image without filling in the margin. (Outputs the
image with the specified area added when the page end
detection mode is set.)
"Detected page bottom" refers to the bottom edge of the
scanned document detected by the scanner.
This setting can also be configured in the scanner driver. In that
case, Page Edge Filler of the scanner driver is used on the
output image.
