40 U41221-J-Z156-1-74
Installing/Removing HDD/Dummy Module FC Hard Disk Drives
Figure 16: Installing the HDD Module
Ê Push the HDD module into the empty slot (1) until it stops .
Ê Push the module handle completely in the direction of the arrow (2) until the
locking mechanism (3) engages.
V CAUTION!
The HDD module must be acclimatized in its operating environment for
an acclimatization time.
Temperature difference (°C)
(operating environment/outside)
Minimum acclimatization time
(hours)
53
10 5
15 7
20 8
25 9
30 10
Table 6: Acclimatization Time for the HDD Module
1
3
2
