U41221-J-Z156-1-74 49
Plug-in Board Modules The FFx-RAID Controller Module
LED
Description
1
DAC DEVICE
ACTIVITY
(green)
4
DAC HOST
ACTIVITY
(green)
-- OFF No FC channel activity on the host side
-- ON FC channel activity on the host side
OFF -- No FC channel activity on the device side
ON -- FC channel activity on the device side
Table 9: FFx-RAID Controller Module: FC channel Activity Indicators
LED
Description
DAC (5); GBIC (6);
HSSDC (3)
NODE STATUS
(yellow/green)
green yellow
OFF OFF Module not inserted or not powered
ON OFF Full Operation: node in the loop active
OFF ON Node not in the loop (generally). Possible causes
on GBICs:
GBIC HW-Error status signals active:
RX_LOS, i. e. the received signal is not valid, or
TX_FAULT, i. e. sender works not correctly
OFF flashing
0.5 sec.
Node disabled from Service Processor (RSB)
ON ON
Module OK; missing or corrupted data
flashing between green
and yellow
approx. 0.5 sec.
Table 10: FFx-RAID Controller Module: Node Status Indicators
