48 U41221-J-Z156-1-74
The FFx-RAID Controller Module Plug-in Board Modules
Description of the LED indicators
LED
Description
7
CACHE
(yellow)
8
DAC
STATUS
(green)
9
DAC
POWER
ALARM
(red)
OFF ON OFF Normal operation, module ready and partner
OK
I This signal is activated only if two
FFx-RAID controller modules are
used; only the non-defective module
can indicate that the other one has
failed.
OFF flashing
0.5 sec.
OFF Normal operation, FFx-RAID controller
module not ready and partner OK.
OFF flashing
1 sec.
OFF Normal operation, FFx-RAID controller
module ready and partner failed
I This signal is activated only if two
FFx-RAID controller modules are
used; only the non-defective module
can indicate that the other one has
failed.
OFF OFF ON Alarm:
FFx-RAID controller not powered (5 VDC;
3.3 VDC)
OFF OFF flashing
0.5 sec.
Alarm:
FFx-RAID controller 5 VDC failed
OFF OFF flashing
1 sec.
Alarm:
FFx-RAID controller 3,3 VDC failed
ON OFF OFF Cache dirty:
Data in cache and on the hard disk drives
are not identical (cache active)
flashing
0.5 sec.
OFF OFF Conservative Cache activated (DIP switch
K1 see “DIP Switches” on page 51)
flashing
0.5 sec.
flashing
0.5 sec.
flashing
0.5 sec.
Diagnosis Mode activated (DIP switch J1
see “DIP Switches” on page 51)
Table 8: FFx-RAID Controller Module: Status Indicators
