100 Options Guide U41593-J-Z156-2-76
Floorstand model Completion
Figure 86: Fastening the left-hand side cover
Ê Fasten the left-hand side cover with the green knurled screw (1).
Ê Insert the key.
Ê Lock the server.
Ê Connect all power plugs to the power outlets.
Ê Press the on/off key to start up the server.
1
