U41593-J-Z156-2-76 Options Guide 19
4 Preparation
V CAUTION!
Observe the safety instructions in the chapter “Safety notes” on
page 13ff.
4.1 Floorstand model
4.1.1 Opening the server
Ê Terminate all applications and shut down the server correctly.
Ê If your operating system has not switched off the sever, press the on/off
switch.
Ê Pull all power connectors out of the power outlets.
Ê If required, remove the lock on the side cover.
Figure 2: Loosening the knurled screw
Ê Loosen the green knurled screw (1).
1
