Fujitsu PRIMERGY TX200 S2 Options Guide

60 Options Guide U41593-J-Z156-2-76
Installing a controller (PCI slot 5) Controller in the PCI slots
8.2 Installing a controller (PCI slot 5)
V CAUTION!
In PCI slot 5 it is obligatory to install the pull-out aid for cooling reasons.
Ê Open the server as described in the chapter “Preparation” on page 19ff.
Figure 48: Removing the pull-out aid
Ê Push the green fastening slider toward the rear (1).
Ê Remove the pull-out aid (2).
2
1
