U41593-J-Z156-2-76 Options Guide 83
13 Conversion standard PS to hot-
plug PS
V CAUTION!
Observe the safety instructions in the chapter “Safety notes” on
page 13ff.
The conversion kit consists of a PS cage, a Power backplane, a PS safe guard
and the power cables.
Figure 67: Conversion kit
Ê Open the server as described in the chapter “Preparation” on page 19ff.
Ê Remove the ventilation duct over the system fans (see page 32).
Ê Remove the processor fan holder (see page 35).
Power backplane
PS cage
PS safe
guard
