84 Options Guide U41593-J-Z156-2-76
Conversion standard PS to hot-plug PS
Figure 68: Removing the guidance of the processor fan holder
Ê Unlock the snap-fit.
Ê Push the guidance of the processor fan holder in direction of the arrow and
take it out.
Ê Disconnect all power cables from the system board and the drives (see the
cabling plans in the Appendix).
Figure 69: Threading the cables
Ê Thread the power cables through the opening.
snap-fit
