102 Options Guide U41593-J-Z156-2-76
Rack model Completion
15.2.2 Closing the server
Figure 88: Attaching the top cover
Ê Position the top cover in such a way that it protrudes approxiate 10 cm at the
rear (1).
Ê Push the top cover all the way forward (2).
Figure 89: Fastening the top cover
Ê Fasten the top cover with the green knurled screw (1).
2
1
1
