U41593-J-Z156-2-76 Options Guide 93
14 Converting from the floorstand
model to the rack model
V CAUTION!
Observe the safety instructions in the chapter “Safety notes” on
page 13ff.
Ê Open the server and remove the front cover as described in the chapter
“Preparation” on page 19ff.
I The front cover is no longer required.
Figure 77: Removing the right-hand side cover
Ê Lift the hook up slightly using a screwdriver.
Ê Push the right-hand side cover in the direction of the arrow.
Ê Lift off the right-hand side cover.
I The right-hand side cover is no longer required.
Ê Lay the server on its right-hand side. Get a second person to help you do
this. The server can weigh up to 40 kg.
Ê Ensure that the feet project over the edge of the table.
