U41593-J-Z156-2-76 Options Guide 21
Preparation Floorstand model
Figure 4: Removing the hard disk cover
Ê Open the server and remove the key.
Ê Push the drive cover up as far as possible (1).
Ê Remove the hard disk cover (2 + 3).
Figure 5: Pulling out the locking buttons
Ê Pull out the two green locking buttons (1+2).
1
2
3
1
2
