Page #123 background imageLoading...
Page #123 background image
Connecting the ScanSnap to a Computer in Access Point
Connect Mode (iX1600 / iX1500)
Configure the wireless settings for the ScanSnap in the ScanSnap Wireless Setup Tool Wizard or on
the touch panel to complete the preparation for connecting the ScanSnap to a computer.
For details, refer to the following:
l "Connecting the ScanSnap to a Wireless Access Point by Using the ScanSnap Wireless Setup
Tool (iX1600 / iX1500)" (page 118)
l "Connecting the ScanSnap to a Wireless Access Point from the Touch Panel (iX1600 / iX1500)"
(page 119)
The following explains how to connect the ScanSnap and a computer when the wireless settings for
the ScanSnap have already been configured.
1. Disconnect the USB cable connecting the ScanSnap to the computer.
ATTENTION
If the ScanSnap Manager icon is , exit ScanSnap Connect Application on the mobile device.
a The ScanSnap is automatically connected to the computer via wireless LAN and the
ScanSnap Manager icon changes to
.
If the icon does not change, go to step 2.
HINT
l If the [Connect automatically to previous ScanSnap by Wi-Fi] checkbox is selected and the
previously connected ScanSnap is available for the connection, the computer is connected to
the ScanSnap automatically.
l The computer can be connected to only one ScanSnap.
l Only one computer can be connected to the ScanSnap via wireless LAN.
2. Right-click the ScanSnap Manager icon
in the notification area located
at the far right of the taskbar and select [Connect by Wi-Fi] from the "Right-
Click Menu" (page 87).
a The [ScanSnap Manager - Connect by Wi-Fi] window appears.
3. From the list of the ScanSnap units to be connected, select the ScanSnap
that you want to connect, and click the [Connect] button.
ATTENTION
If the intended ScanSnap for connection does not appear in the list of the ScanSnap units to be
connected, refer to the ScanSnap Manager Help.
a The ScanSnap is connected to a computer via wireless LAN and the ScanSnap Manager
icon changes to
.
Connecting the ScanSnap to a computer or mobile device via Wireless LAN (iX1600 / iX1500)
123

Table of Contents

Other manuals for Fujitsu ScanSnap iX500

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Fujitsu ScanSnap iX500 and is the answer not in the manual?

Fujitsu ScanSnap iX500 Specifications

General IconGeneral
Film scanningNo
Color scanningYes
Maximum scan size216 x 863 mm
ADF scan speed (b/w, A4)25 ppm
Optical scanning resolution600 x 600 DPI
Scanner typeADF scanner
Product colorBlack
Scan toFile, Image
Sensor typeCIS
Scan file formatsJPG, PDF
Daily duty cycle (max)- pages
Standard input capacity50 sheets
Maximum scan area (ADF)216 x 360 mm
Minimum scan area (ADF)50.8 x 50.8 mm
ISO A-series sizes (A0...A9)A4, A5, A6
ISO B-series sizes (B0...B9)B5, B6
Scanning media types supportedBusiness Card, Plain paper, Post Card(JPN)
Maximum ISO A-series paper sizeA4
Auto Document Feeder (ADF) media weight40 - 209 g/m²
USB version3.2 Gen 1 (3.1 Gen 1)
Standard interfacesUSB 1.1, USB 2.0, USB 3.2 Gen 1 (3.1 Gen 1), Wireless LAN
Mac operating systems supportedMac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Windows operating systems supportedWindows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Input voltage100-240 V
Power supply typeAC
AC input frequency50 - 60 Hz
Power consumption (standby)2.5 W
Power consumption (typical)20 W
Operating temperature (T-T)5 - 35 °C
Operating relative humidity (H-H)20 - 80 %
Sustainability certificatesENERGY STAR
CertificationRoHS
Quantity per pack1 pc(s)
Weight and Dimensions IconWeight and Dimensions
Depth159 mm
Width292 mm
Height168 mm
Weight3000 g
