Screens on the Touch Panel (iX1600 / iX1500)
The screens displayed on the touch panel of the ScanSnap are either the home screen to start
scanning or the [Settings] screen to check or modify the settings of the ScanSnap.
This section explains the following screens:
l "Home screen" (page 104)
l "[Settings] Screen" (page 106)
Home screen
The home screen is a screen where you perform a scan.
When the ScanSnap and a computer are connected, one of the following screens appears.
l When the ScanSnap and the computer are connected via a USB cable
1 2
3
l When the ScanSnap and a computer are connected via wireless LAN
3
1 2
When the ScanSnap and a mobile device are connected, the following screen appears.
Screens and Operations on the Touch Panel (iX1600 / iX1500)
104
