Furuno FS-5000 User Manual

Appendix
AP4-3
Model PCB type ROM Version No. ROM type Note
05P0373
(PANEL)
U1 05-501-29-1xx
HD63B01Y0RDS7P
(Mask ROM)
Main CPU
(05S9131-0)
FM-7000
05P0377
(
SUB-CPU)
U1 05-501-30-1xx
HD63B01Y0RDS8P
(Mask ROM)
Sub CPU
(05S9132-0)
05P0373
(PANEL)
U1 05-501-29-1xx
HD63B01Y0RDS7P
(Mask ROM)
Main CPU
(05S9131-0)
05P0377
(SUB-CPU)
U1 05-501-30-1xx
HD63B01Y0RDS8P
(Mask ROM)
Sub CPU
(05S9132-0)
05P0407
-none
(CONTROL)
05-501-39-141 M27C4001-10F1
DSC CONTROL
For Old type
LCD(yellow)
Full parts
05P0407D
(CONTROL)
U8
05-501-39-142
and after
M27C4001-10F1
DSC CONTROL
For new LCD
type (green)
Reject parts
U2 05-501-40-1xx
Note)
FM-7500
05P0370A
(MODEM)
U3 05-501-40-2xx
WS57C49C-45D DSC MODEM
FM-8000
05P0575
(CPU)
U6 05-501-66-1xx HD6475328CP-10 Control
U2 05-501-83-1xx HD6475328CP-10 RT
FM-8500
05P0616
(CONTROL)
U4 05-501-82-1xx M27C4001-10F1 DSC
U2 05-501-93-1xx HD6475328CP-10 RT
FM-8700
05P0616A
(CONTROL)
U4 05-501-92-1xx M27C4001-10F1 DSC
05P0714
(CONT)
U2 05-502-03-1xx AT28C64B-15TC RT
FM-2721
(FD:both for
RT and HS)
05P0716
(HS C0NT)
U2 05-502-04-1xx HD64F3067RF20
HS-2721
(Hand set)
Note) Refer to section “4.2 Compatibility of CONTROL board,
and LCD module changed”.

Furuno FS-5000 Specifications

General

Output Power	150 W (PEP)
Tuning	Synthesized
Type	MF/HF Radio Transceiver
Frequency Range (Transmit)	1.6 to 27.5 MHz
Frequency Range (Receive)	100 kHz to 30 MHz
Modulation	J3E (SSB), H3E (AM)
Emission Modes	J3E, H3E, F1B, A1A
Power Supply	24V DC
DSC	Yes
