FUTABA 14MZ User Manual

Contents and Technical Specifi cations
(Specifi cations and ratings are subject to change without notice.)
Your 14MZAP or 14MZHP (packaged with a 14-channel PCM-G3 receiver) includes the following components:
• T14MZ Transmitter, including RF module (MZ-DDS)
• R5014 Receiver
• CFDP32M Data-Pack (CF card)
• LT2F2200 Li-ion battery & LBC-1D5 Charger
• NR4F1500 Ni-Cd battery & 110V wall charger (North
America)
• Switch harness/Aileron extension cord/Y-harness/DSC
cord
• Tool Box (includes special jig for adjustment)
• Neck strap
• Frequency Flag
The set contents depend on the type of set.
Transmitter T14MZAP/HP
Operating system: 2-stick, 14 channels, PCM-G3,
synthesizer system
Transmitting frequency: US only 72 or 50 MHz bands
Modulation: PCM-G3, PCM1024, or FM/PPM
switchable.
Power supply: 7.4V LT2F2200 Li-ion battery
Current drain: 1 ampere maximum (RF power on and
back light on) 700mA average
Receiver R5014DPS
(PCM-G3, Synthesizer, Dual conversion)
Receiving frequency: US only 72 or 50 MHz bands
Intermediate freq.: 10.7 MHz & 450 kHz
Power requirement: 4.8 V Ni-Cd battery
Current drain: 75 mA
Size: 52x37.5x16.5 mm
Weight: 33 g.
Channels: 14
Suggested Servos for use with your 14MZ
Servo S9154 (Digital servo)
Control system: Pulse width control, 1.52 ms neutral
Power requirement: 4.8 V (from receiver)
Output torque: 63.9 oz.-in. (4.6 kg-cm) at 4.8V
Operating speed: 0.14 sec/60 at 4.8V
Size: 1.87 x 1.06 x 0.97 in. (47.5 x 27.0 x 25.3 mm)
Weight: 1.87 oz. (53 g)
Servo S9151 (Digital servo)
Control system: Pulse width control, 1.52 ms neutral
Power requirement: 4.8 V (from receiver)
Output torque: 131.9 oz.-in. (9.5 kg-cm) at 4.8V
Operating speed: 0.19 sec/60 at 4.8V
Size: 1.57 x 0.79 x 1.44 in. (40.0 x 20.0 x 36.6 mm)
Weight: 1.79 oz. (50 g)
Servo S9250 (Digital servo)
Control system: Pulse width control, 1.52 ms neutral
Power requirement: 4.8 V (from receiver)
Output torque: 76.4 oz.-in. (5.5 kg-cm) at 4.8V
Operating speed: 0.11 sec/60 at 4.8V
Size: 1.59 x 0.79 x 1.48 in. (40.5 x 20.0 x 37.5 mm)
Weight: 1.90 oz. (54 g)
Servo S9255 (Digital servo)
Control system: Pulse width control, 1.52 ms neutral
Power requirement: 4.8 V (from receiver)
Output torque: 125.0 oz.-in. (9.0 kg-cm) at 4.8V
Operating speed: 0.16 sec/60 at 4.8V
Size: 1.57 x 0.79 x 1.44 in. (40.0 x 20.0 x 36.6 mm)
Weight: 1.94 oz. (55 g)
11
