Servo connection by model type
The T14MZ transmitter channels are automatically assigned for optimal combination according to the
type selected with the Model Type function of the Linkage Menu. The channel assignment (initial setting)
for each model type is shown below. Connect the receiver and servos to match the type used.
*The set channels can be checked at the Function screen of the Linkage Menu. The channel assignments can also be changed. For
more information, read the description of the Function menu.
Airplane/glider/motor glider
●Airplane and V tail
●When a receiver other than the PCM-G3 type is used, only the shaded part of the table above is
valid.
●VC1~4 are vertical channels without receiver output. For more information, see the description of
the Function menu of the Linkage Menu.
46
<Model Basic Setting Procedure>
RX CH
1AIL 2AIL 2AIL+1FLAP 2AIL+2FLAP
Airplane
Glider
Airplane
Glider
Airplane
Glider
Airplane
Glider
EP EP EP EP
1 Elevator Elevator Elevator Elevator Elevator Elevator Elevator Elevator Elevator Elevator Elevator Elevator
2 Rudder Rudder Rudder Rudder Rudder Rudder Rudder Rudder Rudder Rudder Rudder Rudder
3 Throttle Motor AUX1 Throttle Motor AUX1 Throttle Motor AUX7 Throttle Motor AUX6
4 Aileron Aileron Aileron Aileron Aileron Aileron Aileron Aileron Aileron Aileron Aileron Aileron
5 Gear AUX7 AUX7 Aileron2 Aileron2 Aileron2 Aileron2 Aileron2 Aileron2 Aileron2 Aileron2 Aileron2
6 Airbrake Airbrake Airbrake Gear AUX7 AUX7 Flap Flap Flap Gear AUX5 AUX5
7 AUX6 AUX6 AUX6 AUX6 AUX6 AUX6 Gear AUX6 AUX6 Flap Flap Flap
8 AUX5 AUX5 AUX5 AUX5 AUX5 AUX5 AUX5 AUX5 AUX5 Flap2 Flap2 Flap2
9 AUX4 AUX4 AUX4 AUX4 AUX4 AUX4 AUX4 AUX4 AUX4 AUX4 AUX4 AUX4
10 AUX3 AUX3 AUX3 AUX3 AUX3 AUX3 AUX3 AUX3 AUX3 AUX3 AUX3 AUX3
11 AUX2 AUX2 AUX2 AUX2 AUX2 AUX2 AUX2 AUX2 AUX2 AUX2 AUX2 AUX2
12 AUX1 AUX1 AUX1 AUX1 AUX1 AUX1 AUX1 AUX1 AUX1 AUX1 AUX1 AUX1
VC1 AUX1 AUX1 AUX1 Camber Camber Camber Camber Camber Camber Camber Camber Camber
VC2 AUX1 AUX1 AUX1 AUX1 Butterfl y Butterfl y AUX1 Butterfl y Butterfl y AUX1 Butterfl y Butterfl y
VC3 AUX1 AUX1 AUX1 AUX1 AUX1 AUX1 AUX1 AUX1 AUX1 AUX1 AUX1 AUX1
VC4 AUX1 AUX1 AUX1 AUX1 AUX1 AUX1 AUX1 AUX1 AUX1 AUX1 AUX1 AUX1
RX CH
2AIL+4FLAP 4AIL+2FLAP 4AIL+4FLAP
Airplane
Glider
Airplane
Glider
Airplane
Glider
EP EP EP
1 Elevator Elevator Elevator Elevator Elevator Elevator Elevator Elevator Elevator
2 Rudder Rudder Rudder Rudder Rudder Rudder Rudder Rudder Rudder
3 Throttle Motor AUX4 Throttle Motor AUX4 Throttle Motor AUX2
4 Aileron Aileron Aileron Aileron Aileron Aileron Aileron Aileron Aileron
5 Aileron2 Aileron2 Aileron2 Aileron2 Aileron2 Aileron2 Aileron2 Aileron2 Aileron2
6 Gear AUX3 AUX3 Gear AUX3 AUX3 Gear AUX1 AUX1
7 Flap Flap Flap Aileron3 Aileron3 Aileron3 Aileron3 Aileron3 Aileron3
8 Flap2 Flap2 Flap2 Aileron4 Aileron4 Aileron4 Aileron4 Aileron4 Aileron4
9 Flap3 Flap3 Flap3 Flap1 Flap1 Flap1 Flap1 Flap1 Flap1
10 Flap4 Flap4 Flap4 Flap2 Flap2 Flap2 Flap2 Flap2 Flap2
11 AUX2 AUX2 AUX2 AUX2 AUX2 AUX2 Flap3 Flap3 Flap3
12 AUX1 AUX1 AUX1 AUX1 AUX1 AUX1 Flap4 Flap4 Flap4
VC1 Camber Camber Camber Camber Camber Camber Camber Camber Camber
VC2 AUX1 Butterfl y Butterfl y AUX1 Butterfl y Butterfl y AUX1 Butterfl y Butterfl y
VC3 AUX1 AUX1 AUX1 AUX1 AUX1 AUX1 AUX1 AUX1 AUX1
VC4 AUX1 AUX1 AUX1 AUX1 AUX1 AUX1 AUX1 AUX1 AUX1
