FUTABA 14MZ - Gyro Mixing Settings; Adjusting Gyro Sensitivity and Mode

Gyro mixing
This function used to adjust gyro sensitivity. The
sensitivity and operation mode (Normal mode/GY
mode) can be set for each condition.
*Sensitivity setting is assigned to CH3.
Note: Always set both (ACT) and (Trim) for the [Gyro]
function.
● Return to Model Menu
● Touch the [Gyro] button in the Model Menu
to call the setup screen shown below.
Setting method
● Touch the [INH] button of the rate to be used and
display [ON].
● When you want to set the same contents at other
conditions, select the group mode (Gr.). When
you want to set the selected condition only, select
the single mode (Sngl).
● Three rates can be switched for each condition.
(Rate 1/Rate 2/Rate 3)
● A fi ne tuning VR can be set.
Setting example
●
Normally, it is convenient to preset high
sensitivity (Rate 1) and low sensitivity (Rate
2) when either the AVCS mode or Normal
mode is used.
●Selects the selector switch.
●Adjusts the gyro sensitivity by rate.
●Selects [AVCS] or [Nor].
●Select the type of gyro used.
119
<Model Menu (Helicopter Functions)>
