●Return to Linkage Menu
● Touch the [Sub Trim] button in the Linkage Menu
to call the setup screen shown below.
Sub-Trim
Setting of neutral position of each servo.
(The display screen is an example. The screen depends on the model type.)
The Sub-Trim function is used to set the servo
neutral position, and may be used to make fine
adjustments to the control surface after linkages
and pushrods are hooked up. When you begin to set
up a model, be sure that the digital trims are set to
their center position.
Sub trim adjustment
1. Touch the trim display part of the channel
you want to adjust.
Adjustment buttons appears on the Sub Trim
menu screen.
2. Use the adjustment buttons to adjust the sub
trim.
●Initial value: 0
●Adjustment range: -240~+240 (steps)
*See above
3. Repeat this step for each channel.
61
<Linkage Menu>
