Servo speed setting (1)
The speed at each operation (including flight
condition switching) can be adjusted. The
servos operate smoothly at a constant speed
corresponding to the set speed. The operation
speed (In Speed) and the return speed (Out Speed)
can be set individually.
Switch the operation mode according to the set
function. When the button is touched, it toggles
between [LIN] and [SYM].

"SYM" mode: Mode used with ailerons and
other self-neutral functions
"LIN" mode: Mode used with functions which
hold the operation position of the throttle
and switch channel, etc.
[Setting method]
1. Select the function ([LIN] or
[SYM]) matched to the master
channel. Each time the
button is touched, it toggles
between [LIN] and [SYM].
2. Touch the In or Out Speed
button and set the servo
speed.
Initial value: 0
Setting range: 0~25
Operations related to servo speed
Servo speed setting (2)
[Setting method]
1. When setting the servo speed, touch the
Speed button. The Servo Speed setup
screen shown above is displayed.
2. Select the function ([LIN] or [SYM]) matched
to the master channel. Each time the
button is touched, it toggles between [LIN]
and [SYM].
"SYM" mode: Mode used with ailerons and
other self-neutral functions.
"LIN" mode: Mode used with functions which
hold the operating position of the throttle
and switch channel, etc.
3. Touch the In Speed button and set the
servo speed.
Initial value: 0
Setting range: 0~25
4. Touch the Out Speed button and set the
servo speed.
Initial setting: 0
Setting range: 0~25
5. Touch the Start Delay button and set the
delay time from switch ON to the start of
function operation.
Initial setting: 0.0 sec
Setting range: 0~4 secs
6. Touch the Stop Delay button and set the
delay time from switch OFF to the start of
function operation.
Initial setting: 0
Setting range: 0~4 secs
