FUTABA 14MZ - Tailless Wing Servo Assignments

●When a receiver other than the PCM-G3 type is used, only the shaded part of the table above is
valid.
of the Function menu of the Linkage Menu.
●Tailless wing
48
<Model Basic Setting Procedure>
RX CH
2AIL 2AIL+1FLAP 2AIL+2FLAP
Airplane
Glider
Airplane
Glider
Airplane
Glider
EP EP EP
1 Rudder Rudder Rudder Rudder Rudder Rudder Rudder Rudder Rudder
2 Rudder2 Rudder2 Rudder2 Rudder2 Rudder2 Rudder2 Rudder2 Rudder2 Rudder2
3 Throttle Motor AUX1 Throttle Motor AUX7 Throttle Motor AUX6
4 Aileron Aileron Aileron Aileron Aileron Aileron Aileron Aileron Aileron
5 Aileron2 Aileron2 Aileron2 Aileron2 Aileron2 Aileron2 Aileron2 Aileron2 Aileron2
6 Gear AUX7 AUX7 Flap Flap Flap Gear AUX5 AUX5
7 AUX6 AUX6 AUX6 Gear AUX6 AUX6 Flap Flap Flap
8 AUX5 AUX5 AUX5 AUX5 AUX5 AUX5 Flap2 Flap2 Flap2
9 AUX4 AUX4 AUX4 AUX4 AUX4 AUX4 AUX4 AUX4 AUX4
10 AUX3 AUX3 AUX3 AUX3 AUX3 AUX3 AUX3 AUX3 AUX3
11 AUX2 AUX2 AUX2 AUX2 AUX2 AUX2 AUX2 AUX2 AUX2
12 AUX1 AUX1 AUX1 AUX1 AUX1 AUX1 AUX1 AUX1 AUX1
VC1 Elevator Elevator Elevator Elevator Elevator Elevator Elevator Elevator Elevator
VC2 AUX1 AUX1 AUX1 Camber Camber Camber Camber Camber Camber
VC3 AUX1 AUX1 AUX1 AUX1 Butterfl y Butterfl y AUX1 Butterfl y Butterfl y
VC4 AUX1 AUX1 AUX1 AUX1 AUX1 AUX1 AUX1 AUX1 AUX1
RX CH
2AIL+4FLAP 4AIL+2FLAP 4AIL+4FLAP
Airplane
Glider
Airplane
Glider
Airplane
Glider
EP EP EP
1 Rudder Rudder Rudder Rudder Rudder Rudder Rudder Rudder Rudder
2 Rudder2 Rudder2 Rudder2 Rudder2 Rudder2 Rudder2 Rudder2 Rudder2 Rudder2
3 Throttle Motor AUX4 Throttle Motor AUX4 Throttle Motor AUX2
4 Aileron Aileron Aileron Aileron Aileron Aileron Aileron Aileron Aileron
5 Aileron2 Aileron2 Aileron2 Aileron2 Aileron2 Aileron2 Aileron2 Aileron2 Aileron2
6 Gear AUX3 AUX3 Gear AUX3 AUX3 Gear AUX1 AUX1
7 Flap Flap Flap Aileron3 Aileron3 Aileron3 Aileron3 Aileron3 Aileron3
8 Flap2 Flap2 Flap2 Aileron4 Aileron4 Aileron4 Aileron4 Aileron4 Aileron4
9 Flap3 Flap3 Flap3 Flap1 Flap1 Flap1 Flap1 Flap1 Flap1
10 Flap4 Flap4 Flap4 Flap2 Flap2 Flap2 Flap2 Flap2 Flap2
11 AUX2 AUX2 AUX2 AUX2 AUX2 AUX2 Flap3 Flap3 Flap3
12 AUX1 AUX1 AUX1 AUX1 AUX1 AUX1 Flap4 Flap4 Flap4
VC1 Elevator Elevator Elevator Elevator Elevator Elevator Elevator Elevator Elevator
VC2 Camber Camber Camber Camber Camber Camber Camber Camber Camber
VC3 AUX1 Butterfl y Butterfl y AUX1 Butterfl y Butterfl y AUX1 Butterfl y Butterfl y
VC4 AUX1 AUX1 AUX1 AUX1 AUX1 AUX1 AUX1 AUX1 AUX1
●VC1~4 are virtual channels without a receiver output. For more information, see the description
