1.1.2 Specifications
Table 1-2 Specifications
General
Input Voltage
• 13.8 VDC +/- 20%
Main Input Fuse
• 2 A
Typical Power
Consumption
• < 200 mA
Operating
Temperature
• -30 C to +70 C
Storage
Temperature
• -40 C to +85 C
Reverse Polarity
• Protected
Dimensions
Height
• 2.11”
Width
• 7.94”
Depth
• 3.31”
GPIO
Max Input Sink
Current
• 100 mA
