8A089X01 Rev 1
SLIM Installation Manual
3/23/2018 Page 15 of 61
2.2.1.2.3 Keypad Mic
Use the CPS to program keypad mic buttons and set their feature to “Third Party”. For
example, open the CPS, from the left menu open the Radio Ergonomics Configuration
submenu, open the Controls submenu, select Keypad Mic And Accessories, and then for
each desired button set the button’s feature to “Third Party”. Note that keypad buttons
are the same across all radio devices and are programmed in the Keypad options page.
See the image below to identify third-party capable buttons.
Radio Ergonomics Configuration > Controls > Keypad Mic And Accessories> Set
Button’s Feature
Figure 2-7 Keypad Microphone
2.2.1.2.4 DEK’s
Use the CPS to program DEK buttons as one normally would but set their feature to “Third
Party”. For example, open the CPS, from the left menu, open the Radio Ergonomics
Configuration submenu, open the Controls submenu, select DEK, and then for each
desired button set the button’s feature to “Third Party”. See the image below to identify
third-party capable buttons.
Radio Ergonomics Configuration > Controls > DEK > Set Button’s Feature
Figure 2-8 DEK (Direct Entry Keypad)
2.2.1.2.5 Action Consolidation
If a button (or switch position) is set for action consolidation, and will also be used with the
Module, then the button (or switch position) must first be set for Third Party Notification.
To do this, use the CPS to program the Action Consolidation buttons (or switch positions)
