and Light Interface Module port labeled SIREN-C. Connect the other side of the DATA-A
cable to one of the Handheld Interface adapter ports labeled 54WARD.
The Siren and Light Interface Module port labeled SIREN-A should never
be connected to the CTRL HEAD port of the Whelen Handheld Interface
adapter or damage to one or both devices might occur.
4.6.3 Audio
The AUDIO-1 cable provided in interface kit IK-A1 allows the Siren and Light Interface
Module to bring Public Address audio to the siren. Connect one side of the AUDIO-1 cable
to the Siren and Light Interface Module port labeled PA. Connect the other side of the
AUDIO-1 cable to the Cencom siren amplifier port labeled MICROPHONE.
