158 • Appendices DMC-1000
PC/AT Interrupts and Their Vectors
(These occur on the first 8259)
IRQ VECTOR USAGE
0 8 or 08h Timer chip (DON'T USE THIS!)
1 9 or 09h Keyboard (DON'T USE THIS!)
2 10 or 0ah Cascade from second 8259 (DON'T USE THIS!)
3 11 or 0bh COM2:
4 12 or 0ch COM1:
5 13 or 0dh LPT2:
6 14 or 0eh Floppy (DON'T USE THIS!)
7 15 or 0fh LPT1:
(These occur on the second 8259)
IRQ VECTOR USAGE
8 104 or 70h Real-time clock (DON'T USE THIS!)
9 105 or 71h Redirect-cascade (DON'T USE THIS!)
10 106 or 72h
11 107 or 73h
12 108 or 74h Mouse DSR
13 109 or 75h Math Co-processor exception
14 110 or 76h Fixed Disk (DON'T USE THIS!)
15 111 or 77h
ICM-1100 Interconnect Module
The ICM-1100 Interconnect Module provides easy connections between the DMC-1000 series
controllers and other system elements, such as amplifiers, encoders, and external switches. The ICM-
1100 accepts each DMC-1000 ribbon cable (for J2, J3, J4 and J5) and breaks them into screw-type
terminals. Each screw terminal is labeled for quick connection of system elements.
