Galil Motion Control DMC-1000 User Manual

DMC-1000 Appendices • 155
Dip Switch Address Settings
Use this table to find the dip switch settings for any of the available addresses of the DMC-1000. Note: ‘x’ denotes that
the dip switch is ‘ON’.
Address Dip A8 Dip A7 Dip A6 Dip A5 Dip A4 Dip A3 Dip A2
512 x x x x x x x
516 x x x x x x
520 x x x x x x
524 x x x x x
528 x x x x x x
532 x x x x x
536 x x x x x
540 x x x x
544 x x x x x x
548 x x x x x
552 x x x x x
556 x x x x
560 x x x x x
564 x x x x
568 x x x x
572 x x x
576 x x x x x x
580 x x x x x
584 x x x x x
588 x x x x
592 x x x x x
596 x x x x
600 x x x x
604 x x x
608 x x x x x
612 x x x x
616 x x x x
620 x x x
624 x x x x
628 x x x
632 x x x
636 x x
640 x x x x x x
644 x x x x x
648 x x x x x
652 x x x x
656 x x x x x
660 x x x x
664 x x x x
