e.bloxx A6-2CF
SPECIFICATIONS
HB_EBLOXX-A62CF_E_V19.doc
71
Gantner Instruments Test & Measurement GmbH
Linearization of transducer’s
Characteristic curve 8 points
Input mode Edit
Import (e.g. from Excel)
Teach in
Zero balance Over entire measurement range
Balancing time approx. 200 ms, non-volatile memory (secured against power failure)
Tare over entire measurement range
Balancing time approx. 1 ms, selectable volatile or non-volatile memory
Low-pass filter Bessel 4
th
order, 0.1 Hz up to 1,000 Hz (-3 dB), adjustable in steps
Peak-value memory Minimum, maximum
Refresh time 0.5 ms
Delete time 0.3 ms
Momentary value
Refresh time 0.5 ms
Envelope curve Positive, negative
Slew time constant free selectable
Limit Switch Function Switching threshold, tolerance band, hysteresis (2-point control),
all can switch actively or passively,
logical combination of single limit switches
Signal to be processed Selectable
(Gross, net, min/max, peak-peak, envelope, mathematical calculation)
Reference signal Selectable
Constant value, conditioned signal or pre-set value
Response time 1 ms per channel
Hysteresis Selectable
Conditioning Formula generator
e.g. peak-to-peak value, envelope, run/hold, scaling, addition, multiplication.
Complex coherences can easily be shown by using combinations of measured or conditioned values and I/O signals.
7.3. Analog Outputs
Number 2
Output Voltage ±10.2 V, freely scalable
