Gantner e Series User Manual

e.bloxx A6-2CF
SPECIFICATIONS
72 HB_EBLOXX-A62CF_E_V19.doc
Gantner Instruments Test & Measurement GmbH
Max. load resistance: > 5 k Ω
Resolution of DAC: 16 bit
Frequency range: 1,000 Hz (-3 dB)
Signal source: Every analog output could be controlled with a measurement or a conditioned signal
Temperature influence
on Zero (TC
0
) 2 mV / 10 °K
on Sensitivity (TC
C
) 0.05 % / 10 °K
Noise voltage for ranges
0 … 10 Hz 2 mV
0 … 1,000 Hz 10 mV
Long-time drift 1 mV / 48 h
Linearity deviation 0.01 %
7.4. Digital Inputs
Number 6, active circuit (high/low)
Function 6 x state (tare, reset, run/hold…)
or
single counter and 5 x status
or
up/down, quadrature counter and 4 x status
max. 50 kHz
32 bit
or
frequency measurement and 5 x status
Time base 0.01 to 10 s
Input voltage max. 30 V
Input current max. 6 mA
High switching threshold >10 V (high)
Low switching threshold <2.0 V (low)
7.5. Digital Outputs
Number 4
Function Process-, host controlled
Reaction time 1 ms per channel
Type of output Open Collector
Output current max. 100 mA
Output voltage max. 30 V
7.6. Communication Interface
Standard RS 485, 2-wire
Data format 8E1
Protocols ASCII, MODBUS, PROFIBUS-DP, LOCAL-BUS
