e.bloxx A6-2CF
SPECIFICATIONS
HB_EBLOXX-A62CF_E_V19.doc 73
Gantner Instruments Test & Measurement GmbH
Baud rates
ASCII and MODBUS-RTU 19.2, 38.4, 57.6, 93.75, 115.2 kbit/s
PROFIBUS-DP 19.2, 93.75, 187.5, 500, 1500 kbit/s
LOCAL-BUS 19.2, 38.4, 57.6, 93.75, 115.2, 187.5, 500, 1500 kbit/s
Connectable devices up to 32 without repeater
up to 127 with repeater
Isolation voltage 500 V
7.7. Power Supply
Power supply 10 VDC to 30 VDC
overvoltage and overload protection
Power consumption approx. 5 W
Influence of voltage 0.001 % / V
Permitted residual ripple 3 Vpp
7.8. Mechanical
Case Aluminium and ABS
Dimensions (W x H x D) 69.7 x 90 x 83 mm (2.7 x 3.5 x 3.3 inch)
Protective system IP 20
Weight 250 g
Mounting DIN EN-Rail
7.9. Connection
Plug-in screw terminals wire cross-section up to 1.5 mm²
Rapid bus connector 4-pin plug in ABS-housing
7.10. Environmental Conditions
Operating temperature -20 °C to + 60 °C (-4 °F to +140 °F)
Storage temperature -30 °C to +85 °C (-22 °F to +185 °F)
Relative humidity 0% to 95% at +50 °C(+122 °F), non-condensing
