Supervisor Overview
Supervisor Menus
DS2000-TS Administrator’s Guide
2 - 9
2.4.2 Network Menus
The Network menu and its submenus provide the means to configure and check the local area network setup
(e.g., IP Router and Ethernet switch). Selecting the <2> Network submenu from the Main menu displays
the Networking Setup and Status menu shown in Figure 2-8.
Figure 2-8. Networking Setup and Status Menu
Through these setup and status menu items, the user can configure the system Router, Terminal Server, and
Async settings for all of the ports and connections to the DS2000-TS. The configuration options include:
• Router - Setup and Status
• IP port configuration
• IP Routes and display
• IP static route setup
• IP filters
• TCP/IP status
• OSPF (Open Shortest Path First) (not operational in the DS2000-TS)
• DHCP (Dynamic Host Configuration Protocol)
• VPN (Virtual Private Network)
• VRRP (Virtual Router Redundancy Protocol) (not operational in the DS2000-TS
• TCP Multicast
• Terminal Server - Configuration
• Async - Services
• PAD (Packet Assembler Disassembler) profile settings
• Logon screen settings
A complete reference for the Networking Setup and Status menus is in Appendix B, “Network Commands”.
2.4.3 System Menus
Selecting option <3> Systems from the Main menu displays the System Functions sub-menu shown in
Figure 2-9. Within these submenus, the user can:
*** Networking Setup and Status ***
1 - Router Configure and display router options
2 - Terminal Server Configure Async-TCP/IP terminal server
3 - Async Services Configure Async options
Enter command number:
_________[DynaStar_6b2c]__________
Terminate input with <RET> Press ESC to return to previous menu
