Router (IP)
DS2000-TS Administrator’s Guide
B - 10
B.2.5 TCP/IP Status
This screen is accessed from the Main Menu by selecting <2> Network, <1> Router, <5> TCP/IP Status.
The screen, shown in Figure B-9, displays the connection status of the TCP devices with current
connections to the DS2000-TS. The fields shown in this screen can help assist the user in determining if
connections are being made to the DS2000-TS as well as the port connections made and if traffic is passing.
Figure B-9. TCP Connection Status
*** TCP Connection Status ***
Local Remote Remote Protocol State Window Service/LCN or
Port IP Address Port TX RX Multicast Src
23 111.115.195.212 1905 TELNET CONNECTED 65135 1460
__________[DynaStar_24]___________
Press <RET> for update Cursor up/down for more entries
Press <CTRL-D> to clear call Press ESC to return to previous menu
