GarrettCom DynaStar DS2000-TS User Manual

A
PPENDIX
B -
Network Commands
Terminal Server
DS2000-TS Administrator’s Guide
B - 23
B.3 T
ERMINAL
S
ERVER
The path to the Terminal Server menu is Main menu, <2> Network, <2> Terminal Server, the Terminal
Server Configuration menu is shown in Figure B-20 and provides access to the serial port configuration
parameters. In the Terminal Server menu the Type field is fixed unless you press <CTRL-O> which
displays the Advanced Terminal Configuration menu, shown in Figure B-21. The Port field is also fixed and
the menu in Figure B-20 shows the default values for the ports. The fields in the Terminal Server
Configuration menus are described in Tabl e B-5. The Advanced Terminal Server Configuration menu is
used to set the direction of the terminal server function. For terminal server out connections the default IP-
ASY (IP to asynchronous) setting is correct. to configure for reverse operation the user toggles the Type
field value to ASY-IP. For further discussion on this feature refer to “Terminal Server Overview” on page
1-2.
Figure B-20. Terminal Server Configuration Menu
Table B-5. Terminal Server Configuration Attributes
Parameter Description Default Range
Port Shows the port number None S1 through S32
Name Port name Serial-S1 through
Serial-S32
As defined by
user - up to 14
characters
Type (Fixed) Not changeable in this menu, see
advanced menu to toggle.
IP-ASY IP-ASY
ASY-IP
Local Socket Socket number assigned to port 10101 for Serial1,
10102 for Serial2,
etc.
1 - 16959
*** Terminal Server Configuration ***
Last changed: 0-0-90 0:00:00
Port Name Type Local Tel Async Parity DSS Profile
(14) (Fixed) Socket Raw Speed Ignore
S0 Sync/Async IP-ASY 10003 N 9600 Baud 7-EVEN N 89(14) CRT
S1 SERIAL-S1 IP-ASY 10101 N 9600 Baud 7-EVEN N 89(14) CRT
S2 SERIAL-S2 IP-ASY 10102 N 9600 Baud 7-EVEN N 89(14) CRT
S3 SERIAL-S3 IP-ASY 10103 N 9600 Baud 7-EVEN N 89(14) CRT
S4 SERIAL-S4 IP-ASY 10104 N 9600 Baud 7-EVEN N 89(14) CRT
S5 SERIAL-S5 IP-ASY 10105 N 9600 Baud 7-EVEN N 89(14) CRT
S6 SERIAL-S6 IP-ASY 10106 N 9600 Baud 7-EVEN N 89(14) CRT
S7 SERIAL-S7 IP-ASY 10107 N 9600 Baud 7-EVEN N 89(14) CRT
S8 SERIAL-S8 IP-ASY 10108 N 9600 Baud 7-EVEN N 89(14) CRT
S9 SERIAL-S9 IP-ASY 10109 N 9600 Baud 7-EVEN N 89(14) CRT
S10 SERIAL-S10 IP-ASY 10110 N 9600 Baud 7-EVEN N 89(14) CRT
S11 SERIAL-S11 IP-ASY 10111 N 9600 Baud 7-EVEN N 89(14) CRT
S12 SERIAL-S12 IP-ASY 10112 N 9600 Baud 7-EVEN N 89(14) CRT
S13 SERIAL-S13 IP-ASY 10113 N 9600 Baud 7-EVEN N 89(14) CRT
S14 SERIAL-S14 IP-ASY 10114 N 9600 Baud 7-EVEN N 89(14) CRT
_________[DynaStar_6b2c]__________ Process selections (Y/N): Y
<RET> to toggle or type value Press ESC to return to previous menu
Cursor up/down for more entries Press <CTRL-O> for more options
Use <CTRL-D> to delete entry
