GarrettCom DynaStar DS2000-TS User Manual

A
PPENDIX
B -
Network Commands
Router (IP)
DS2000-TS Administrator’s Guide
B - 22
Figure B-19. TCP Multicast Screen
The destination IP address and socket are entered in the IP Address and Socket columns. Toggle the Source
Socket to obtain the source socket for this destination. In the Source Name, toggle to obtain the source name.
Note that destinations can be terminated on the same DS2000-TS as the source. They can be converted to
X.25 via X25-OUT, or they can be routed to another device.
*** Multicast Destinations ***
Last changed: 0-0-90 0:00:00
IP Address Socket Source Socket Source Name
1 0.0.0.0 0 0
__________[DynaStar_11]___________ Process selections (Y/N): Y
Use <CTRL-D> to delete entry <RET> to toggle or type value
Use <TAB> and CURSOR to move fields Press ESC to return to previous menu
