A
PPENDIX
B -
Network Commands
Router (IP)
DS2000-TS Administrator’s Guide
B - 6
The entry “E0 ETHER” applies to the on-board Ethernet port. Providing an IP address for this port enables
Supervisor access via this port. Enter the designated IP address and sub-net mask.
When an address is entered, RIP will appear as the default protocol and Enet II will appear as the default
encapsulation. If RIP is the desired routing protocol, no further action is needed.
If RIP is not the desired routing protocol, toggle this field to select the desired entry: RIP, RIP-II, RIP-RX
(receive-only RIP) or “None.”
B.2.2 IP Routes Display
The IP Routes Display menu provides details on the internal IP router. The menu shows the ARP and
Routing tables. The Routing tables can be extensive and the menu provides scrolling capabilities by using
the <CTRL-Q>, scroll, and <CTRL-S>, stop scrolling, to look at the complete table. The menu can also be
updated by pressing the Enter key and can be flushed by pressing <CTRL-F>. Use caution when
considering flushing the learned tables. Immediately after flushing the tables, the router will be unable to
Route messages until the routing protocols rebuild the table. RIP discovery typically takes at least 30
seconds. Refer to Figure B-5 for a sample IP Addresses menu.
Figure B-5. IP Addresses Menu
B.2.3 Static Routing
As described above, the IP router can use RIP (the default), RIP-II, RIP-RX, no routing protocol, or Static
Routing. This section describes how the Static Routing Table is defined.
To establish Static Routes for IP routing, enter <3> IP Static Routes at the Router Setup And Status sub-
menu. Figure B-6 will appear.
*** IP Addresses ***
ARP Table:
IP Address Port MAC Address Age
75.142.45.121 103 0020610012AA 120
Routing Table:
Network Address Network Mask Next Hop Port Metric Age VCN OWNER
75.142.45.240 255.255.255.240 E1 0 0 LOC
122.128.7.0 255.255.255.240 75.142.45.121 E1 1 238 RIP
__________[DynaStar_24]___________ Press <CTRL-F> to Flush the Tables
Use XOFF <CTRL-S> and XON <CTRL-Q> Press <RET> for update
to control scroll. Press ESC to return to previous menu
Local MAC Address: 00200ab06b2c
